Portable Competition Horse Stalls

The Portable Competition Horse Stalls are designed for temporary yet secure housing for horses during shows, fairs, expos, racetracks, or private events. Available in 10’ and 12’ lengths with a 7’ height, these stalls feature 48” wide door openings with a pin spring latch for easy access. The sturdy frames are constructed from 1.5” square tubing with 1” turned spindles on the fronts, and all tubing is built with 1/8” wall thickness for durability. The stall fronts and dividers are equipped with ¼” thick puck board (HDPE high-density plastic) panels, known for their strength, noise reduction, and moisture resistance.

Puck board, used in ice hockey arenas, is highly durable and lightweight, ensuring a quiet, low-maintenance, and chew-proof environment for horses. The pins are attached to the frames, preventing loss during events. The stalls also come with a top frame designed for easy transport via loader, forklift, or skid steer. For added convenience, stalls can be pinned back-to-back or in a line for multiple stall setups.

Dimensions:

• 10’ Stall: 117” long (outside frame to outside frame)
• 12’ Stall: 141” long (outside frame to outside frame)

Optional:

• Portable Horse Stalls Roof System (pricing available upon request)

The Lakeland Portable Box Stalls offer strength, ease of use, and safety, making them ideal for temporary situations while maintaining the durability needed for horses.

Features:

• 10’L or 12’L lengths x 7’H Stall Fronts & Dividers
• 48’’W Door Opening with pin spring latch for easy access in and out
• 1.5’’ Square Tube Frames with 1’’ turned spindles on the fronts
• All tubing is 1/8th wall thickness.
• Puck board (HDPE high density plastic) is ¼’’ thick
• Pins included and do not separate from the frames (saves losing connecting pins at events)
• Frame on top to pick up with loader, forklift or skidsteer

Dimensions:

• Actual dimensions of portable box stalls, from outside of frame to outside of frame (not including pin brackets):
  • 10ft length would measure 117″ long
  • 12ft length would measure 141″ long

What is Puck Board and why we use it?

• Puck board is the same material that is used to line the inside of ice hockey arenas, so this material can take a serious beating even in freezing temperatures!
• It is a 1/4″ thick high-density plastic that is extremely durable and low maintenance
• Reduces the noise level that you’d normally get with the crashing and banging of steel sheeted sides. Less noise, less stress!
• It is moisture resistant
• It is lightweight, so makes it easy to pick up and move around
• Horses cannot chew through puck board, as they potentially could with wood sides

PHSDA10 – 10′ Stall Divider – Aluminum. Includes puckboard.
PHSFA10 – 10′ Stall Front – Aluminum. Included puckboard. (145 lbs)
PHSBA10 – 10′ Stall Back – Aluminum. Includes puckboard.

Made in North America
